Aluminum Ceiling

Direct Factory Manufacturer

Aluminum Ceiling Systems (Clip-In, Lay-In, Linear Strip & Baffle Ceilings)

Shandong Jixiang Decoration and Building Material Co., Ltd. manufactures premium suspended aluminum ceiling systems including clip-in tiles, square panels, linear strip ceilings, and acoustic metal ceilings. Designed for modern office spaces, commercial complexes, transport hubs, and residential interior projects worldwide.

Product Application-01

6,000,000 m²

Annual Production Capacity

120+ Acres

Industrial Factory Complex

5 Auto Lines

Hot-Pressing & Coating

CE / SGS / CTC

Verified Quality Standards

Tailored B2B Solutions for Ceiling Contractors & Wholesalers

Solving core procurement and structural requirements for modern commercial interior spaces.

For Commercial Contractors

Buying Pain Point: Difficult maintenance access to overhead MEP HVAC systems and slow grid assembly.

Jixiang Solution: Modular Clip-In / Lay-In suspension systems providing fast installation and easy individual panel removal for duct maintenance.

For Architects & Designers

Buying Pain Point: Monotonous interior aesthetics and demanding acoustic insulation standards in public spaces.

Jixiang Solution: Versatile curved linear strips, baffle ceilings, and acoustic sound-absorbing non-woven backing paper options.

For Wholesale Distributors

Buying Pain Point: Surface discoloration, edge warping, and high freight damage rates on thin metal panels.

Jixiang Solution: Automatic continuous roller coating for zero color difference, rigid alloy tempering, and seaworthy export box packaging.

Aluminum Ceiling Specifications & Technical Parameters

Comprehensive options for tile dimensions, edge profiles, surface treatments, and acoustic perforations.

Parameter Standard Specification Custom / OEM Wholesale Options
Standard Tile Sizes 300x300mm, 600x600mm, 300x1200mm, 600x1200mm Tailored non-standard linear and square dimensions
Panel Thickness 0.5mm, 0.6mm, 0.7mm, 0.8mm, 1.0mm 0.4mm - 1.2mm high-tensile aluminum alloy gauge
System Type Clip-In (Concealed), Lay-In (T-Grid), Linear Strip Custom baffle screen grids, hooked ceiling systems
Surface Coating Powder Coating, Roller Coating, PVDF Coating Wood Grain Heat-Transfer, Anodized, High Gloss
Acoustic Treatment Plain Solid or Perforated (Ø1.8mm / Ø2.3mm) Black acoustic non-woven sound-absorbing backing
Color Selection Matt White, Silver Gray, Metallic Gray Full RAL color code matching available

Installation Process & System Integration Guide

Standardized suspended ceiling installation procedure ensuring high structural integrity and rapid job-site execution.

1. Elevation Line Marking

Mark precise ceiling height lines and hanger points using laser levels within a 5mm margin of error.

2. Edge Trim Installation

Fix color-matched L-shape or C-shape aluminum perimeter wall trims firmly along wall lines.

3. Carrier Grid Suspension

Suspend main keels and light steel sub-carriers with adjustable threaded rod hangers.

4. Panel Clipping & Fitting

Snap aluminum ceiling tiles into spring carriers, working systematically from center to sides.

Wholesale Ordering & OEM Workflow

1. Project Inquiry

Send us your ceiling system type, dimensions, perforation requirements, and quantities.

2. Sample & Quote

Receive competitive factory wholesale pricing and physical sample swatches for review.

3. Mass Production

High-speed automated continuous roller coating and precision metal shearing under ISO standards.

4. Global Shipping

Reinforced carton packaging and seaworthy palletized loading for international export.

Frequently Asked Questions (FAQ)

Q: What are the main benefits of using aluminum ceilings over traditional drywall ceilings?

Aluminum ceilings are lightweight, moisture-proof, fire-resistant, and non-corrosive. Unlike drywall, modular metal ceiling tiles allow easy access to overhead piping, cabling, and HVAC systems without damaging the ceiling finish.

Q: What is the difference between Clip-In and Lay-In aluminum ceilings?

Clip-In systems use a concealed suspension grid where tiles snap into spring carriers from below for a concealed, flush look. Lay-In systems drop tiles into an exposed T-grid framework, providing quick panel removal.

Q: Do you offer acoustic soundproofing options for metal ceiling panels?

Yes, we supply perforated aluminum ceiling tiles backed with black acoustic non-woven fleece, providing excellent sound absorption for offices, auditoriums, and conference rooms.

Q: What is the typical lead time for custom aluminum ceiling container orders?

Standard full container load (FCL) production and custom coating orders typically ship within 15 to 20 days upon deposit and technical drawing approval.

Ready to Source Commercial Aluminum Ceilings?

Contact our sales and technical engineering team today for factory-direct wholesale prices, architectural catalogs, and sample kits.

We're well-known as one of the leading aluminum ceiling manufacturers and suppliers in China. If you're going to buy or wholesale high quality aluminum ceiling at competitive price, welcome to get pricelist from our factory.
